buy tormach 1100MX machine

Get the best CNC machine deal

Tormach 1100MX machine

buy tormach 1100MX machine FROM the offcial UK Tormach Distributor

We are overstocked due to a shipping error...
So, we have an incredible one-time offer...

buy tormach 1100MX machine

The Tormach 1100 MX

Normally £22,050

We have​
10 available

from
£19,995

FINANCE AVAILABLE, PLEASE ASK!

ONLY 6 LEFT!

at this incredible price and we won't ever be able to match it again.

Fill out this short form and we’ll send you an easy to browse catalogue WITH prices

As thank you for taking a moment to fill in the from, we’ll also send you a checklist which you can use before you go to cut, useful no matter what CNC machine you buy!

FREE catalogue
and checklist

Yes! I would like the catalogue and checklist!

Ian Hillier-2-1

Create a Masterpiece

Tormach’s CNC are the first choice all around the world for hobbyists, small businesses and large companies.

Cut through the work

Tormach CNC machines cut through wood, plastics, aluminium, stainless, hardened steel and even titanium.

FULL Support

The complete Tormach range with FULL UK sales and support. Tormach is affordable, modular and expandable.

Buy Tormach 1100MX machine

TECHNICAL SPECIFICATIONS

Travels:

X-Axis:18 in.(457 mm)
Y-Axis: 11 in. (279 mm)
Z-Axis: 16.25 in.(413 mm)

Travels

X-Axis: 18 in. (457 mm)
Y-Axis: 11 in. (279 mm)
Z-Axis: 16.25 in. (413 mm)

Spindle

Spindle Power: 2 hp / 1.49 kW
Maximum Speed: 10,000 RPM
Transmission: Poly-V belt
Spindle Taper: BT30
Thread Machining: Rigid Tapping, Tension/Compression, Thread Mill

Maximum Feed Rate

X- and Y-Axis: 300 IPM (7.62 m/min)
Z-Axis: 230 IPM (5.84 m/min)

Power

Power Required: Single-Phase 230 Vac, 50/60Hz, 20A breaker

Tormach 1100 MX
Machine Specifications

Table Size: 34 in. × 9.5 in. (863 mm x 241 mm)
Table Slots: 5/8 in. – Three slots (15.9 mm – Three slots)
Spindle Nose to Table Max Clearance: 16.5 in. (419 mm)
Spindle Centerline to Machine Column: 11 in. (279 mm)
Typical System Footprint: 69 in. × 56.5 in. (1753 mm x 1435 mm)
Overall System Height: 96 in. (2438 mm)
Typical System Weight: 1600 lb (726 kg)
Maximum Weight on Table: 500 lbs (227 kg)

Frame

Frame and Table: Cast iron frame and table, with hand-scraped hydrodynamic ways and tapered adjustment gibs

Way Surfaces: Low-friction PTFE-filled, Acetyl-bonded sliding surface. Similar to Rulon® and Turcite®.

Warranty

1-Year Warranty against defects in material and workmanship. Extended Warranty available.

If you are considering to buy Tormach 1100MX machine it offers several compelling reasons why it could be an excellent investment for your needs:

  • The Tormach 1100 offers excellent accuracy and precision in machining operations. Its rigid construction and quality components contribute to consistent and reliable results.
  • The machine comes equipped with user-friendly software and interfaces, making it accessible to users with varying levels of CNC machining experience. This ease of use allows for quicker learning and setup times.
  • If you buy Tormach 1100MX machine, it has a relatively compact footprint, making it suitable for smaller workshops or limited spaces without compromising on its machining capabilities.
  • Tormach offers a range of add-ons and accessories that allow users to customise their Tormach 1100 CNC machine to meet their specific needs and expand its capabilities as their projects evolve.
  • Compared to larger and more industrial-grade CNC machines, the Tormach 1100 is more budget-friendly, making it an attractive option for those starting in CNC machining or looking for a cost-effective solution.
  • The Tormach 1100 can handle a variety of materials, including metals, plastics, and composites, making it suitable for a wide range of projects and applications.
  • If you buy Tormach 1100MX machine, it can be upgraded with additional features or improved components to keep up with evolving requirements.
  • Tormach has a dedicated user community where individuals can exchange knowledge, share tips, and discuss best practices, providing valuable support and resources for users.
  • Tormach offers responsive customer support, assisting users with technical questions, troubleshooting, and any concerns they may have.
